| Order code | 4001 |
| Power Supply | 3N ~380V 50/60HZ |
| Welding diameter | Φ100~Φ1000mm |
| Types of welding plates | Tin plated sheet, galvanized sheet, cold-rolled sheet, stainless steel sheet |
| Welding thickness | Cold rolled plate: 0.3~1.0mm Galvanized sheet: 0.3~1.0mm Stainless steel: 0.3~0.8mm Tinplate: 0.3~1.0mm |
| Welding height | ≤1000mm |
| welding speed | 3~9m/min |
| Overlap quantity | 4~6mm |
| Welding copper wire | Φ2.0mm |
| Cooling water | 0.4MPa 8.5L/min |
| Cooling water | 0.8MPa 600L/min≤25°C |
| Welding power | 50KVA |
| Altitude | ≤1000m |
| weight | 2T |
